304 304L 316 Stainless Steel Angle Bar ASTM Corrosion Resistant

Ask Lasest Price
Brand Name :	TISCO LISCO POSCO JISCO BAOSTEEL.etc
Model Number :	304 304L
Certification :	SGS CE BV ISO
Price :	2060 USD/Ton
Payment Terms :	L/C, T/T , Western Union,D/P
Supply Ability :	5000 Ton
Delivery Time :	7 - 10 work days

Add to Cart

Product Details
Company Profile

304 304L 316 Stainless Steel Angle Bar ASTM Corrosion Resistant

304 304L 316 Stainless Steel Angle Bar Structure Ship Tower

Angle steel is a carbon structural steel for construction, which is a section steel with a simple section, mainly used for metal components and the frame of a workshop. Widely used in various building structure and engineering structure, such as the beam, Bridges, transmission tower, lifting transportation machinery, ships, industrial furnace, reaction tower, container frame and warehouse shelves, etc.

Material	201 304 304L 309S 310S 321 316L 2205 904L . etc	Size	4 # - 20 #
Company Type	Storage And Factory	Certificates	SGS , BV
Type	Equal And Unequal	Standard	ASTM
Length	1 - 12m	Technique	Hot Rolled
Product Name	Stainless Steel Angle	Dimensions	20 * 20mm * 3mm - 250 x 250 x 35mm
Shape	Equilateral Angle Bar
High Light:	304 Stainless Angle Bar , Corrosion Resistant Stainless Angle Bar , Door Closer Steel Brackets

Dimensions of 304 Stainless Steel Equal Angle

Sizes (all Dimensions in milimeter)	Approx Weight SS Angle Bar (kilogram / meter)	SS 304 Angle Bar Sizes (all Dimensions in milimeter)	Approx Weight SS 316 Angle Bar (kilogram / meter)
25 x 25 x 3	1.13	63 x 63 x 8	7.50
25 x 25 x 4	1.46	65 x 65 x 4	4.00
25 x 25 x 5	1.78	65 x 65x 5	5.02
30 x 30 x 3	1.37	65 x 65 x 8	7.75
30 x 30 x 4	1.78	70 x 70 x 5	5.35
30 x 30 x 5	2.20	70 x 70 x 6	6.40
40 x 40 x 3	1.83	75 x 75 x 6	6.85
40 x 40 x 4	2.41	75 x 75 x 8	9.05
40 x 40 x 5	2.97	80 x 80 x 6	7.35
50 x 50 x 4	3.05	80 x 80 x 8	9.65
50 x 50 x 5	3.78	80 x 80 x 10	11.98
63 x 63 x 4	3.90	100 x 100 x 8	12.20
63 x 63 x 5	3.90	100 x 100 x 12	18.00

Chemical Element of SS 304 Unequal Angle

Grade	C	Mn	Si	P	S	Cr	Mo	Ni
Stainless 304	0.08 max	2 max	0.75 max	0.045 max	0.030 max	18 – 20	–	8 – 11
Stainless 304L	0.035 max	2.0 max	1.0 max	0.045 max	0.03 max	18 – 20	-	8 – 13
Stainless 316	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 - 18.00	2.00 - 3.00	11.00 - 14.00
Stainless 316L	0.035 max	2.0 max	1.0 max	0.045 max	1.0 max	16.00 - 18.00	16.00 - 18.00	10.00 - 14.00

Mechanical Properties of 316 Stainless Steel Unequal Angle

Density	Melting Point	Tensile Strength	Yield Strength (0.2 % Offset)	Elongation
8.0 g / cm 3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

Competitive Advantage

All products are made of high - quality imported raw materials.

Our products are certified by ISO9001 : 2008 authentication quality systems.

We are nominated as the AAA enterprise by Jiangsu government.
