ASTM AISI 316l Stainless Steel U Channels 10x50x5mm Hot Rolled

Ask Lasest Price
Brand Name :	TISCO LISCO POSCO JISCO BAOSTEEL.etc
Model Number :	304 316 316L
Certification :	SGS CE BV ISO
Price :	2060 USD/Ton
Payment Terms :	L/C, T/T , Western Union,D/P
Supply Ability :	5000 Ton
Delivery Time :	7 - 10 days

Add to Cart

Product Details
Company Profile

ASTM AISI 316l Stainless Steel U Channels 10x50x5mm Hot Rolled

Astm Aisi 316l Stainless Steel U Channel 100 * 50 * 5mm Hot Rolled U Channel

Description

Hot Rolled 304 316L Stainless Steel Channel U Channel 304 Stainless Channel Bar

The Stainless Steel U Channel is like a square. The best way to produce it is to make all of the portions symmetrical. We offer 316L and 304L U channels that are extremely durable and very reliable. U channel is offered in laser fused non-tapered with smooth bead blast finish. We can offer custom made to order U channel up to 40’ long

Products	Stainless Steel U Channel	Grade	304 316 316L
Size	3 # - 20 #	Length	6m
Type	Hot Rolled	Service	Cutting
Company	Factory	Other Materials	Angle Bar, Square Bar, Hexagon Bar
High Light	sus316l stainless steel u channel , aisi 316l u channel bar , 5mm hr stainless steel u channel

Standard	ASTM A276
Condition	hot rolled
Size Range	50374.5 - 20010010
Thickness	4.5mm - 10mm
Grades	304, 316
Processing	Bar cutting

The Dimensions of Stainless Steel U Channels

The dimensions of stainless steel channels are the same dimensions that apply to each of our products. There is height, width, thickness, and length; these all need to fit certain measurements. However, the height and width are key factors in deciding what kind of channel you will want to purchase. Depending on these factors you could be purchasing a C-channel or a U-channel.

Hot rolled stainless steel channels: dimensional tolerances meet ASTM A276, ASTM A484, ASTM A479, ASME SA479. Laser fused stainless steel channels are produced to ASTM A1069/A1069M/11, dimensional tolerances, and grades according to ASTM A276, ASTM A484, ASTM A479/A479M

Chemical composition of our 304 and 316L stainless steel

Grade	C	Mn	Si	P	S	Cr	Mo	Ni
SS 304	0.08 max	2 max	0.75 max	0.045 max	0.030 max	18 – 20	–	8 – 11
SS 304L	0.035 max	2.0 max	1.0 max	0.045 max	0.03 max	18 – 20	-	8 – 13
SS 316	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 - 18.00	2.00 - 3.00	11.00 - 14.00
SS 316L	0.035 max	2.0 max	1.0 max	0.045 max	1.0 max	16.00 - 18.00	16.00 - 18.00	10.00 - 14.00

Other Product

Number	Products name	Grade
1	stainless steel angle bar	304 316L 310S 321.etc
2	stainless steel hexagon bar	304 316L 310S 321.etc
3	stainless steel round bar	304 316L 310S 321.etc
4	stainless steel square bar	304 316L 310S 321.etc
5	stainless steel H beam	304 316L 310S 321.etc
